377086021912 BLUELINE PTO Drive Shaft Series F21 Lz 860mm for Tractors up to 16HP
377086021912 BLUELINE PTO Drive Shaft Series F21 Lz 860mm for Tractors up to 16HP
iPhotos are indicative: the product may differ in some details. Refer to the specifications.
BluelineRef.

377086021912 BLUELINE PTO Drive Shaft Series F21 Lz 860mm for Tractors up to 16HP

BLUELINE F21 Series PTO Drive Shaft - L 860mm (Code 377086021912)

€99.00VAT incl.
Coupon -€1.98 -2% sul carrello

Sconto extra riservato ai clienti registrati

Accedi per sbloccare il codice

Prezzo finale con coupon: €97.02

Not sure it fits?Message us with your tractor model
WhatsApp
Secure paymentsEasy returnsFree shipping over €30 + VAT

Description

The BLUELINE F21 Series drive shaft (860 mm) is a reliable transmission component designed for low-power agricultural applications. Featuring the classic Lemon Profile, this model provides consistent performance for light-duty implements such as sprayers, small fertilizer spreaders, or hay rakes. With a nominal torque of 210 Nm, it ensures safe and efficient operation for standard utility tasks.

Technical Specifications

Part Number: 377086021912

Series: F21 (Standard Version)

Total Length (Lz): 860 mm

Profile A (Tractor Side): 1 3/8" 6 Splines

Profile B (Implement Side): 1 3/8" 6 Splines

Cross Kit Dim. (Profile A/B): 22 x 54.8 mm

Locking System: Push-button / Push-button (G1/G2 Coupling)

Tube Profile: Lemon Profile

Performance Data

Power at 540 rpm: Up to 16 HP (12 kW)

Power at 1000 rpm: Up to 24 HP (18 kW)

Nominal Torque (540 rpm): 210 Nm

Nominal Torque (1000 rpm): 170 Nm

Operating instructions are included. For lemon profile shafts, ensure that the telescopic tubes are adequately lubricated to allow for smooth axial movement during implement operation.
