New Holland TD D Series Hydraulic Top Link 700mm 50937 | Raim Store

Hydraulic Top Link Cylinder for New Holland Tractors Cat. 2 Quick Hook Part Number 50937

star star star star star_border
Aftermarket
50937

The heavy-duty hydraulic top link cylinder (code 50937) is engineered for agricultural tractor 3-point hitches, specifically adaptable to New Holland tractors from the TD D Series (models TD 55D, TD 60D, TD 65D, TD 70D, TD 75D, TD 80D, TD 85D, TD 90D, TD 95D). It features a minimum length of 700 mm, a stroke of 370 mm, a 70 mm bore, and a 35 mm rod diameter. It comes equipped with a Cat. 2 National quick-release hook on the rod end, a Ø 25.4 mm ball joint on the cylinder base end, and a 3/8" dual pilot check valve.

Hurry! only 2 items left in stock.
€358.99
Tax included
COUPON
- € 7,18
Final price: € 351,81
Quantity

Last 2 items
Add to Compare
Add to Wishlist
Security Policy
Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy
Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments
Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Hydraulic Top Link Cylinder 700x70x35 for New Holland - Code 50937

The heavy-duty hydraulic top link cylinder (Product Code: 50937) is a professional-grade hydraulic actuator engineered for precision alignment, real-time geometry adjustment, and secure load retention of three-point linkage implements. Designed to be perfectly adaptable to New Holland tractor specifications, this dual-acting cylinder allows operators to adjust implement pitch angles dynamically from the cabin, maximizing working field performance and shifting efficiently into safe road transport configurations.
Design Details and Functionality
This hydraulic top link comes fully equipped with a standard dual-pilot check safety valve threaded to 3/8". The check valve provides a robust mechanical locking force, maintaining rod stroke configurations even under sudden hydraulic hose ruptures or line pressure drops, shielding field implements from accidental dropping. The specific hardware layout features a heavy-duty spherical rod eye end with a 25.4 mm pin bore hole on the cylinder base side (tractor linkage), paired with an automatic quick-release catch hook classified under Category 2 National on the rod end side (implement linkage). The combination of a 70 mm cylinder bore diameter, a high-tensile 35 mm micro-polished chrome rod, and an extended 370 mm stroke provides great mechanical reliability along with high thrust and retraction load parameters, making this link perfectly suited for a wide range of agricultural implements performing heavy-duty tasks.
Technical Specifications
Component Classification Double-acting hydraulic top link actuator cylinder
Brand Compatibility New Holland (Adaptable)
Minimum Length (Retracted) 700 mm
Cylinder Stroke 370 mm
Cylinder Bore Diameter (D) 70 mm
Piston Rod Diameter (d) 35 mm
Piston Rod End Fitting (F) Automatic quick-release latch catch hook - Cat. 2 National
Cylinder Base End Fitting (P) Spherical knuckle joint swiveling ball eye Ø 25.4 mm
Hydraulic Port Connection 3/8" BSP threads (with pre-assembled pilot-operated dual check safety valve)
Product Code 50937
Tractor Applications & Compatibility
Tractor Series Compatible Models
TD D Series TD 55D, TD 60D, TD 65D, TD 70D, TD 75D, TD 80D, TD 85D, TD 90D, TD 95D
