Fuel Lift Pump 230 l/h 0.55 bar 38017524 | Raim Store

Mechanical Diaphragm Fuel Lift Pump Without Filter 230 l/h Part 38017524

star star star star star_border
Aftermarket
38017524

The diaphragm fuel lift pump without filter (part number 38017524) is a high-delivery fuel pump engineered with a flow rate of 230 l/h and an operating pressure range of 0 - 0.55 bar. Designed for absolute reliability in agricultural environments, it is compatible with New Holland, CNH, Ford, and Sisu engines. This replacement pump directly fits Case IH (CVX, MXM Series), Fendt (200 Series), Massey Ferguson (5400, 6400, 7400 Series), New Holland (TM, TS, T7500 Series), and Steyr (CVT Series) tractors.

Hurry! only 3 items left in stock.
€105.00
Tax included
COUPON
- € 2,10
Final price: € 102,90
Quantity

Last 3 items
Add to Compare
Add to Wishlist
Security Policy
Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy
Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments
Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Mechanical Diaphragm Fuel Lift Pump (Filterless Version) - Code 38017524

The professional-grade mechanical diaphragm fuel lift pump in filterless configuration (Product Code: 38017524) is a high-delivery, low-pressure fluid transfer component engineered to maintain a steady fuel feed toward the main high-pressure injection setup. Tailored explicitly for agricultural and industrial powertrain setups operating under severe structural loads, this pump guarantees consistent operational reliability. Its heavy-duty design makes it perfectly suitable for an expansive fleet range of tractors and combine harvesters across leading global brands including Case IH, New Holland, Fendt, Massey Ferguson, and Steyr.
Design Details and Fluid-Dynamic Performance
This mechanical transfer pump stands out for its exceptional volumetric efficiency, precisely calibrated for mid-to-high displacement internal combustion diesel engines. The unit delivers a high-capacity flow rate of up to 230 l/h, while balancing operating pressure constants within a calibrated range of 0 to 0.55 bar. This calibrated metric isolates delivery line drops and dampens fuel cavitation factors. The specialized filterless configuration is engineered specifically for fuel system layouts equipped with secondary bulk filter modules or independent water-separators upstream, ensuring unhindered flow cross-sections. Its internal diaphragm matrix is composed of advanced high-elasticity elastomers that retain material memory, preventing premature structural splitting caused by chemical fuel interactions and extreme engine bay thermal gradients.
Technical Specifications
Component Classification Mechanical diaphragm fuel lift pump / low-pressure transfer pump (Filterless version)
Maximum Volumetric Flow Rate 230 l/h
Operating Pressure Range 0 - 0.55 bar
Core Engine Compatibility New Holland 675 TA/AA, CNH 675/TA, Ford 675TA, Sisu 66 (Tier 3 systems)
Original Equipment (OE) Cross References CNH / Fiat / Ford: 87802238, 84271407, 162000080914, 162000080883
Fendt / Massey Ferguson: V837073629, V837079281, 837079281
Product Reference Code 38017524
Application Fleet & Equipment Compatibility Range
Manufacturer / Brand Fleet Series & Compatible Agricultural / Industrial Models
CASE IH CVX Series: 140, 150, 160, 175, 195, 1135, 1145, 1155, 1170, 1190, 1195
MXM Series: 120, 130, 135, 140, 150, 155, 165, 175, 180, 190
FENDT Fendt 200 Series: 207 (Typ 330), 207 V+F (Typ 260), 208 (Typ 331), 208 V+F (Typ 261), 209 (Typ 332), 209 P (Typ 272), 209 V+F (Typ 262), 210 (Typ 333), 210 P (Typ 273), 210 V+F (Typ 263), 211 (Typ 334), 211 P (Typ 274), 211 V+F (Typ 264)
FIAT / FORD M Series: M 100, M 115, M 135, M 160
10 Series: 5610, 6610, 7010, 7610, 8010
60 Series: 8160, 8260, 8360, 8560
500 / 600 Series: 555, 575, 655
MASSEY FERGUSON 3600 Series (incl. 2nd Gen): 3630, 3640, 3650
5400 Series: 5465, 5475 (Sisu Tier 3 engine specs)
6400 Series: 6465, 6475, 6480, 6485, 6490, 6495 (Tier 3 builds)
7400 Series: 7465, 7475, 7480, 7485 Dyna VT, 7490 Dyna VT, 7495 Dyna VT (Tier 3 builds)
NEW HOLLAND TM Series: TM110, TM115, TM120, TM125, TM130, TM135, TM140, TM150, TM155, TM165, TM175, TM180, TM190
TS Series: TS90, TS100, TS110, TS115, TS120
TVT / T7500 Series: TVT135, TVT145, TVT155, TVT170, TVT190, TVT195, T7510, T7520, T7530, T7540, T7550
Skid Steers & Backhoes: 5 Series (655), L Series (L865), LB Series, LS Series (LS180, LS190), LX Series (LX865, LX985), NH-TLB layouts
STEYR CVT Series: 6135 CVT, 6140 CVT, 6145 CVT, 6150 CVT, 6155 CVT, 6160 CVT, 6170 CVT, 6175 CVT, 6190 CVT, 6195 CVT
: 38017524
