Goldoni Hydraulic Top Link 600mm Cat. 2 51252 | Raim Store

Hydraulic Top Link Cylinder for Goldoni Tractors Cat. 2 National Quick Hook Part Number 51252

star star star star star_border
Aftermarket
51252

The heavy-duty hydraulic top link cylinder (code 51252) is engineered for agricultural tractor 3-point hitches, custom-designed to fit Goldoni tractors. It features a minimum length of 600 mm, a stroke of 238 mm, a 60 mm bore (cylinder diameter), a 30 mm rod diameter, and a net weight of 11.5 kg. The rod end is equipped with a Cat. 2 National quick-release hook, while the cylinder base end features a Ø 19.3 mm ball joint. Complete with a 3/8" dual pilot check valve, it is perfectly adaptable to Goldoni 3000 Series (3050, 3070), Compact series (614D, 654, 664, 774), Star Quadrifoglio (4000 Q), and Star series (50, 70, 75) tractors.

Hurry! only 1 items left in stock.
€280.00
Tax included
COUPON
- € 5,60
Final price: € 274,40
Quantity

Last 1 items
Add to Compare
Add to Wishlist
Security Policy
Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy
Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments
Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Hydraulic Top Link Cylinder for Goldoni Tractors - Code 51252

The professional-grade hydraulic top link cylinder (Product Code: 51252) is a high-precision hydraulic actuator engineered specifically for implement alignment and real-time geometry adjustment on compact and orchard tractors under the Goldoni brand. This double-acting cylinder (net weight 11.5 kg) allows operators to modify the implement pitch angle directly from the driver seat, maximizing field operation accuracy and easing row-end turns.
Design Details and Functionality
This hydraulic top link comes fully equipped with an integrated double-acting pilot-operated check valve threaded to 3/8". This device acts as a critical safety mechanism, locking the rod stroke position firmly in place even during sudden hydraulic system pressure drops or fluid hose ruptures. The specific mechanical layout features a swiveling spherical knuckle joint ball with a 19.3 mm bore on the cylinder base side (tractor attachment), combined with an automatic quick-release catch hook classified under Category 2 National on the rod end side (implement attachment) for quick and safe operational connections. The combination of a 60 mm cylinder bore diameter and a high-tensile 30 mm polished rod ensures an excellent balance between force and response speed, making it perfect for specialized orchard, vineyard, and greenhouse machinery.
Technical Specifications
Component Classification Double-acting hydraulic top link actuator cylinder
Brand Compatibility Goldoni (Adaptable)
Minimum Length (Retracted) 600 mm
Cylinder Stroke 238 mm
Cylinder Bore Diameter (D) 60 mm
Piston Rod Diameter (d) 30 mm
Piston Rod End Fitting (F) Automatic quick-release latch catch hook - Cat. 2 National
Cylinder Base End Fitting (P) Spherical swiveling ball eye joint Ø 19.3 mm
Hydraulic Port Connection 3/8" BSP threads (with pre-assembled pilot-operated dual check safety valve)
Net Component Weight 11.5 kg
Product Code 51252
Tractor Applications & Compatibility
Tractor Series Compatible Models
3000 Series 3050, 3070
COMPACT Series Compact 614D, Compact 654, Compact 664, Compact 774
STAR QUADRIFOGLIO Series Star 4000 Q
STAR Series Star 50, Star 70, Star 75
