Bondioli & Pavesi 81970 | 1-Bank Valve DE Position B

Bondioli & Pavesi MD Hydraulic Valve 1-Bank Double Acting Detent Position B 3/8" Code 81970

star star star star star_border
Bondioli & Pavesi
81972

Buy Bondioli & Pavesi 81970 hydraulic valve. MD series, 1-lever double acting with fixed position B, 40 l/min, 3/8" BSP. Professional hydraulic control.

Hurry! only 5 items left in stock.
€97.90
Tax included
COUPON
- € 1,96
Final price: € 95,94
Quantity

High availability
Add to Compare
Add to Wishlist
Security Policy
Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy
Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments
Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Bondioli & Pavesi MD series monoblock hydraulic valve, 1 lever for double-acting circuits. Special version with detent (position B) and left-side inlet, ideal for applications requiring constant operational flow without continuous manual intervention.
Product Description
The Bondioli & Pavesi hydraulic valve (Internal Code) is a professional component designed for managing double-acting applications that require continuous operation modes. The main feature of this MD model is the lever configuration: position "1" is a fixed (detent) type, allowing the oil flow to be locked in one direction, while position "2" is equipped with the classic automatic spring return to the "0" neutral center. With a flow rate of 40 l/min and a maximum pressure of 180 Bar, this valve ensures smooth and precise control. The compact monoblock structure, 3/8" Gas ports, and left-side inlet make it extremely versatile for installation on agricultural machinery, small loaders, and industrial equipment requiring reliability and high quality standards.
Technical Data and Composition
Brand Bondioli & Pavesi
Circuit Type Double Acting (D.A.)
Lever Operation 0: Fixed | 1: Fixed | 2: Spring Return
Max Flow Rate 40 l/min
Max Working Pressure 180 Bar
Hydraulic Ports 3/8" Gas - Left Inlet
Net Weight 1.70 Kg
: 81972
