Same Dorado Landini Advantage Hydraulic Top Link 500mm 50760 | Raim Store

Hydraulic Top Link Cylinder for Same Dorado, Landini Advantage, and Lamborghini Part Number 50760

star star star star star_border
Aftermarket
50760

The heavy-duty hydraulic top link cylinder (code 50760) features a minimum length of 500 mm, 208 mm stroke, 60 mm bore, and 30 mm rod (weight 9 kg). Equipped with a dual Ø 25.4 mm ball joint and a 3/8" check valve, it perfectly fits orchard and utility tractors including Same (Dorado 60/70, Argon 50, Golden 65/75/85), Landini Advantage Series (3 & 4 cyl FP, GE, GTP, LP models), Lamborghini (Sprint 664-60/65, 674-70, 990-F Plus), and Deutz-Fahr Agroplus (60, 70).

Out of Stock
€175.00
Tax included
COUPON
- € 3,50
Final price: € 171,50
Quantity

Out of stock
Add to Compare
Add to Wishlist
Security Policy
Security Policy

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policy
Shipping Policy

Fast & Reliable Shipping. Orders handled with care. Various options available.

Secure Payments
Secure Payments

Secure Payments! Transactions protected by encryption. Your safety is guaranteed.

Hydraulic Top Link Cylinder 500x60x30 with Dual Ball Joints - Code 50760

The heavy-duty hydraulic top link cylinder (Product Code: 50760) is a professional-grade hydraulic actuator engineered for precision alignment, real-time geometry adjustment, and secure load retention of three-point linkage implements. Featuring a reinforced dual-acting architecture with a minimum retracted length of 500 mm and a net weight of 9 kg, this mechanism is ideally suited for orchard, vineyard, and compact utility tractors, allowing operators to adjust implement pitch angles dynamically from the cabin.
Design Details and Functionality
This hydraulic top link comes fully equipped with a standard dual-pilot check safety valve threaded to 3/8". The check valve provides a robust mechanical locking force, sealing fluid within the cylinder chambers to maintain the structural rod configuration even under sudden line pressure drops or hydraulic hose ruptures, shielding suspended field implements from accidental dropping. The hardware layout features a symmetrical Category 2 configuration, with standard spherical knuckle joint swiveling ball eyes on both the cylinder base side (tractor linkage) and the rod end side (implement linkage), each machined with a 25.4 mm pin bore hole. The combination of a 60 mm cylinder bore diameter, a high-tensile 30 mm micro-polished chrome rod, and a 208 mm stroke provides exceptional mechanical reliability along with fast hydraulic response, making this link ideal for specialized agricultural implements working in narrow rows or sloped terrains.
Technical Specifications
Component Classification Double-acting hydraulic top link actuator cylinder
Brand Compatibility Same / Deutz-Fahr / Lamborghini / Landini (Adaptable)
Minimum Length (Retracted) 500 mm
Cylinder Stroke 208 mm
Cylinder Bore Diameter (D) 60 mm
Piston Rod Diameter (d) 30 mm
Piston Rod End Fitting (F) Spherical knuckle joint swiveling ball eye Ø 25.4 mm (Cat. 2)
Cylinder Base End Fitting (P) Spherical knuckle joint swiveling ball eye Ø 25.4 mm (Cat. 2)
Hydraulic Port Connection 3/8" BSP threads (with pre-assembled pilot-operated dual check safety valve)
Net Component Weight 9 kg
Product Code 50760
Tractor Applications & Compatibility
Manufacturer Compatible Series & Models
DEUTZ FAHR AGROPLUS: Agroplus 60, Agroplus 70
LAMBORGHINI SPRINT: 664-65 Sprint, Sprint 664-60, Sprint 674-70
F PLUS: 990-F Plus
LANDINI ADVANTAGE 3 CYL F.S. (1992-1999): 60FP, 60GE, 60GTP, 60LP
ADVANTAGE 4 CYL F.S. (1992-1999): 65FP, 65GE, 65GTP, 65LP
ADVANTAGE 4 CYL CAB (1992-1999): 65L Cab
SAME ARGON: Argon 50 | DORADO: Dorado 60, Dorado 70 (Stage 3A)
GOLDEN: Golden 65 Compact, Golden 75 Compact, Golden 85 Compact
: 50760
